NLZL500-1000型自流式灌裝機

詳細介紹

用途與簡介/Brief Introduction:

該機采用特殊三通灌裝閥,適用于水劑和膏霜類產品的灌裝,特別對高粘度物料(如濃醬、辣椒醬、番茄醬、種衣劑、微乳劑、懸浮劑等)的效果比較明顯,且精度高。該機采用PLC可編程控制,配以6英寸觸摸屏人機界面系統,實行自動進瓶,自動灌裝,自動出瓶,電器,氣動元部件均采用國際品牌,確保了出色的質量和持久穩定的性能。本設備結構簡單,操作方便,是國內理想的針對高粘度物料的灌裝設備。該機配備了防止滴漏與拉絲的灌裝悶頭,確保灌裝完畢后無滴漏,無拉絲。

Filling valve, the machine USES special tee is suitable for the filling agent and cream products, especially for high viscosity material (such as thick sauce, chili sauce, tomato sauce, indicated, micro emulsion, suspending agent, etc.) of the effect is obvious, and high precision. The machine USES PLC programmable control, with 6 inch touch screen man-machine interface system, implements the automatic into the bottle, automatic filling, automatic bottle, electric, pneumatic components adopt international brand, to ensure that the performance of the outstanding quality and lasting stability. This equipment has simple structure, convenient operation, is the ideal filling equipment for high viscosity material. The machine is equipped with prevent drip with wire filling cocks, ensure filling after the completion of a drip-tight, no drawing.



特點/Characteristic:

◆控制系統——采用三菱PLC控制系統,灌裝劑量隨機微調。

Control system adopt mitsubishi PLC control system, filling dose random tweaks

◆操作界面——6英寸彩屏手觸式操作界面,直觀簡單、安全可靠

Interface - 6 inches color hand touch interface operation, intuitive and simple, safe and reliable

◆功能改進——下料有防滴漏裝置,可根據物料特性具備下潛灌裝功能。(此功能可以選用)

Improvements - blanking drip tight device, according to the material properties have diving filling function. (this function can be chosen)

◆電器元件——均采用國際知名品牌,確保設備的安全可靠、準確性高;

Electrical components adopt international famous brand, to ensure the equipment safe and reliable, high accuracy;

◆機械部件——機器部件均采用優質304不銹鋼制作,如有需要接觸物料可以采用316L另計費用。

Mechanical parts, machine parts are made of high quality 304 stainless steel material can be used if necessary contact 316 l in extra costs.

◆計數檢測——實時計數,對工作產量直觀反映。

Counting test, real-time, intuitive reflect the yield of work.

◆灌裝檢測——無瓶不灌、瓶數不夠不灌

Bottle filling test - no bottle no filling, not enough

◆維護情況——本機符合GMP要求,可輕松拆卸、清洗維護。

Maintenance - the machine is in line with the GMP requirements, easy disassembly, cleaning maintenance.

◆調換規格——更換灌裝規格時,只需要簡單調整,輕松搞定。

Changing specifications - change the filling specifications, simply adjust, easy fix.

◆環保配置——配置了環保框架,使機器的操作環境更加清潔衛生。(此環保配置可以選配)

Environmental protection configuration, configuration framework of environmental protection, make the operation of the machine environment more clean sanitation. (the environmental protection configuration can be selected)

技術參數/technical parameters:

灌裝頭數The number of filling head

8頭(可選4、6、8、10、12個灌裝頭)8 head (optional 4, 6, 8, 10, 12 filling head)

適用瓶徑 Applicable bottles Drive

Ф33-Ф100 mm

計量精度measure precision

±1%

罐裝容量Canned capacity

150-1000ml

生產能力Production Capacity

2400-4000瓶/小時2400-4000   bottles per hour

氣源壓力bleed pressure

0.7-0.9mpa

電    源Power Supply

380 伏/50 HZ

總 功 率The total power

0.5 kw

外形尺寸 boundary dimension

6000×850×1800 mm

重    量Weight

500kg
